ROTABROACH, ELENENTS 100, MAGNETIC DRILLING MACHINE
$3,984.75
| Brand: | Rotabroach |
| Product Code: | Element 100/1 / Element 100/3 |
| Availability: | In Stock |
Add to cart
Buy Now
-
- Rotabroach’s Largest Machine With Large Diameter Drilling And Cutting Depths.
- Suitable For Drilling Up To 100mm Diameter By 100mm Depth.
- The ‘Element 100’ Offers Forward And Reverse Functionality For Tapping.
- The ‘Element 100’ Can Be Supplied As A Swivel Base Or A Non-Swivel Base.
- The Element Range Uses A Unique Dual Motor Protection System Prolonging The Machines Life And Preventing Unwanted Wear.
Model Number Element 100/1 / Element 100/3 Motor Specification 110V 2000W / 230V 2000W No Load RPM Gear 1: 45-129 RPM Gear 2: 70-208 RPM
Gear 3: 150-434 RPM
Gear 4: 240-700 RPM
Max Hole Cutting Capacity Ø100 X 100mm Deep – 31.75 With MT Drill Overall Dimensions Height: 560mm / Width: 230mm With Capstan / Length: 460mm With Guard Machine Weight 24.8kg Magnetic Adhesion 20,000N Magnet Size 228mm X 114mm Safety Features Cutsmart™ Technology / Fixed Guard / Magnetic Detection
